Mining Portable Piston Air Compressor

Type:Piston
Electric Power:11-18.5kw
Diesel engine: single 10-25hp
Air capacity : 1.25-4m³/min
Air pressure:3-5Bar

Get A Quote

Product Description

Variety scope: more than 100 products of fixed and mobile type; air cooling and water cooling type; diesel and electric type. Compressor of this series is reciprocating piston air compressor which mainly provides compressed air for pneumatic tools and pneumatic control system. It is extensively used in mining, machine manufacturing, civil engineering, food, textile, bridge and road construction, and petrochemical industry. The machine is equipped with single cylinder diesel or small motor, thus it is compact, portable and suitable for breaking road surface with the help of air pick and for secondary crushing in mine with the help of rock drill.

Technical Parameters of Mining piston Air Compressor

Model	Supporting Power (kW)	Capacity(m³/min)	Working pressure(Mpa)	Dimensions (long×width×high)
W-1.35/5-D	11	1.35	0.5	1390×640×980
W-1.35/5	S1100	1.35	0.5	1390×640×980
W-1.8/5-J-D	11	1.8	0.5	1700×710×1000
W-1.8/5-J	S1100	1.8	0.5	1700×710×1000
W-1.8/5-D	11	1.8	0.5	1700×710×1000
W-1.8/5	S1100	1.8	0.5	1700×710×1000
W-2/5-D	11	2	0.5	1700×810×1050
W-2/5	S1100	2	0.5	1700×810×1050
W-2.6/5-D	15	2.6	0.5	1780×870×1235
W-2.6/5	S1110	2.6	0.5	1780×870×1235
W-2.8/5-D	15	2.8	0.5	1780×870×1235
W-2.8/5	S1110	2.8	0.5	1780×870×1235
W-2.8/5-G-D	15	2.8	0.5	1780×870×1235
W-2.8/5-G	S1115	2.8	0.5	1780×870×1235
W-2.8/5-G-DZ	15	2.8	0.5	1780×870×1235
W-3/5-D	18.5	3	0.5	1800×900×1300
W-3/5	S1115	3	0.5	1800×900×1300
2V-3.5/5-D	18.5	3.5	0.5	1800×950×1300
2V-3.5/5	S1125	3.5	0.5	1800×950×1300
2V-4/5-D	18.5	4	0.5	1800×950×1300
2V-4/5	S1125	4	0.5	1800×950×1300
W-1.8/7-D	11	1.8	0.7	1100×820×1100
W-1.8/7	S1100	1.8	0.7	1100×820×1100
W-2.6/7-D	15	2.6	0.7	1800×870×1235
W-2.6/7	S1115	2.6	0.7	1800×870×1235
W-3.2/7-D	18.5	3.2	0.7	1920×960×1350
W-3.2/7	S1125	0.7	0.7	1920×960×1350
W-2.5/3-D	11	2.5	0.3	1780×870×1235
W-2.5/3	S1110	2.5	0.3	1780×870×1235
