Drilling method: Tophammer

Hole diameter: 64 mm - 127 mm

Cabin: Yes

Maximum hole depth: 25 m

Engine: 260hp/194kW

Air capacity (FAD): 9.7m³/min

Air pressure:10Bar

Drilling method: Down-the-hole

Hole diameter: 90 mm - 130 mm

Automatic drilling depth:28m

Auto load/unload drill rod system: Yes

Engine: 320hp/235kW

Air capacity (FAD): 18m³/min

Air pressure:22Bar

Drilling method: Down-the-hole

Hole diameter: 115 mm - 152mm

Cabin: Yes

Maximum hole depth: 28 m

Engine: 360hp/264kW

Air capacity (FAD): 20m³/min

Air pressure:22Bar

Drilling method: Down-the-hole

Hole diameter: 90 mm - 105 mm

Cabin: Yes

Maximum hole depth: 24 m

Engine: 240hp/176kW

Air capacity (FAD): 12m³/min

Air pressure：15bar

Drilling method: Down-the-hole

Hole diameter: 90 mm - 125 mm

Cabin: Yes

Maximum hole depth: 32 m

Engine: 310hp/242kW

Air capacity (FAD): 18m³/min

Air pressure:17Bar

Drilling method: Down-the-hole

Hole diameter: 115 mm - 165 mm

Automatic drilling depth:24m

Auto load/unload drill rod system: Yes

Engine: 400hp/295kW

Air capacity (FAD): 20m³/min

Air pressure:22Bar

Drilling method: Down-the-hole

Hole diameter: 90 mm - 127 mm

Automatic drilling depth:24m

Auto load/unload drill rod system: Yes

Engine: 220hp/162kW

Air capacity (FAD): 13m³/min

Air pressure:18Bar

Drilling method: Down-the-hole

Hole diameter: 90 mm - 140 mm

Cabin: Yes

Maximum hole depth: 32 m

Engine: 325hp/242kW

Air capacity (FAD): 18m³/min

Air pressure:20Bar

Drilling method: Down-the-hole

Hole diameter: 90 mm - 115 mm

Automatic drilling depth:24m

Auto load/unload drill rod system: Yes

Engine: 220hp/162kW

Air capacity (FAD): 13m³/min

Air pressure:16Bar

Drilling method: Down-the-hole

Hole diameter: 90 mm - 115 mm

Cabin: No

Auto load/unload drill rod system: No

Engine: 220hp/162kW

Air capacity (FAD): 12m³/min

Air pressure:15Bar
